Combine Sewer Cleaning Vehicles

Standard Type Combined Vehicles
The sewer opening vehicles (Kuka) is specially equipped on-board equipment designed to open the plugged sewer ducts with pressurized water. Volume of the water tank mounted on the vehicle is designed regarding the load capacity of axle of the vehicle and the maximum payload. The water from the tank is pumped through the high pressure sewer hose to the septic ducts by the high pressure water pump. Power transmission to the pump is carried out using an intermediate gearbox. The hose reels on the equipment are suitable for the desired length of the hoses and are produced hydraulically or mechanically in accordance with the demands of our customers.
There is also a washing gun available for washing on the equipment. Water tanks can be filled from hydrants or other vehicles by tank filling valves or manhole covers on the tank. Our equipment is designed in accordance with the needs of our customers and is produced in the best quality and the most suitable features to meet the needs.
Download the BrochureStandard Type Combined Vehicles KRB-KOM8-21
Vehicle Carrying Capacity | At least 8500 kg |
Splitted Tank | 3000 Lt |
Clean Water Capacity | 1000 Lt |
Waste Water Capacity | 2000 Lt |
Tank Material | Carbon steel |
Vacuum Pump Capacity | 500-850 m3/Hour |
High Pressure Pump Capacity | 110-180 Lt / min at 100-160 bars |
Opening the Back Cover | Hydraulic |
Main Hose Drum | 80 mt Length 3/4 " diameter |
Auxiliary Hose Drum | 1/2"-60 mt Manual Winding System |
Rear Cover Locks | Hydraulic |
Valves | Mechanical Discharge and Intake Valves |
Cabinets | On both sides of the tank along the tank |
-
Standard Accessories
-
Optional Accessories
Standard Type Combined Vehicles KRB-KOM10-31
Vehicle Carrying Capacity | At least 10000 kg |
Splitted Tank | 4000 Lt |
Clean Water Capacity | 1000 Lt |
Waste Water Capacity | 3000 Lt |
Tank Material | Carbon steel |
Vacuum Pump Capacity | 500-850 m3/Hour |
High Pressure Pump Capacity | 110-180 Lt / min at 100-160 bars |
Opening the Back Cover | Hydraulic |
Main Hose Drum | 80 mt Length 3/4 " diameter |
Auxiliary Hose Drum | 1/2"-60 mt Manual Winding System |
Rear Cover Locks | Hydraulic |
Valves | Mechanical Discharge and Intake Valves |
Cabinets | On both sides of the tank along the tank |
-
Standard Accessories
-
Optional Accessories
Standard Type Combined Vehicles KRB-KOM15-42
Vehicle Carrying Capacity | At least 15000 kg |
Splitted Tank | 6000 Lt |
Clean Water Capacity | 2000 Lt |
Waste Water Capacity | 4000 Lt |
Tank Material | Carbon steel |
Vacuum Pump Capacity | 500-2700 m3/Hour |
High Pressure Pump Capacity | 120-160 Bar'da 120-260 Lt/Dk |
Opening the Back Cover | Hydraulic |
Main Hose Drum | 80 mt Length 3/4 " diameter |
Auxiliary Hose Drum | 1/2"-60 mt Manual Winding System |
Rear Cover Locks | Hydraulic |
Valves | 4" Manuel operated suction and 6" pneumatic discharge valves |
Cabinets | On both sides of the tank along the tank |
-
Standard Accessories
-
Optional Accessories
Standard Type Combined Vehicles KRB-KOM18-53
Vehicle Carrying Capacity | At least 18000 kg |
Splitted Tank | 8000 Lt |
Clean Water Capacity | 3000 Lt |
Waste Water Capacity | 5000 Lt |
Tank Material | Carbon steel |
Vacuum Pump Capacity | 700-2700 m3/Hour |
High Pressure Pump Capacity | 260-410 lpm at 155-170 bar |
Opening the Back Cover | Hydraulic |
Main Hose Drum | 120 mt Long 1" Hose |
Auxiliary Hose Drum | 1/2"-60 mt Manual Winding System |
Rear Cover Locks | Hydraulic |
Valves | 4" Manuel operated suction and 6" pneumatic discharge valves |
Cabinets | On both sides of the tank along the tank |
-
Standard Accessories
-
Optional Accessories
Standard Type Combined Vehicles KRB-KOM25-85
Vehicle Carrying Capacity | At least 25000 kg |
Splitted Tank | 13000 Lt |
Clean Water Capacity | 5000 Lt |
Waste Water Capacity | 8000 Lt |
Tank Material | Carbon steel |
Vacuum Pump Capacity | 1500-4500 m3/Hour |
High Pressure Pump Capacity | 330-410 lpm at 155-230 bar |
Opening the Back Cover | Hydraulic |
Main Hose Drum | 120 mt Long 1" Hose |
Auxiliary Hose Drum | 1/2"-60 mt Manual Winding System |
Rear Cover Locks | Hydraulic |
Valves | 4" Manuel operated suction and 6" pneumatic discharge valves |
Cabinets | On both sides of the tank along the tank |
-
Standard Accessories
-
Optional Accessories
Standard Type Combined Vehicles KRB-KOM32-96
Vehicle Carrying Capacity | At least 32000 kg |
Splitted Tank | 15000 Lt |
Clean Water Capacity | 6000 Lt |
Waste Water Capacity | 9000 Lt |
Tank Material | Carbon steel |
Vacuum Pump Capacity | 2400-9500 m3/Hour |
High Pressure Pump Capacity | 350-480 lpm at 170-230 bar |
Opening the Back Cover | Hydraulic |
Main Hose Drum | 120 mt Long 1" Hose |
Auxiliary Hose Drum | 1/2"-60 mt Manual Winding System |
Rear Cover Locks | Hydraulic |
Valves | 6" manuel operated suction and 6" pneumatic discharge valves |
Cabinets | On both sides of the tank along the tank |
-
Standard Accessories
-
Optional Accessories
